What is the expansion tank for water heater

The expansion tank is designed to handle the thermal expansion of water as it heats up in the water heater, preventing excessive water pressure. If water pressure gets to high it can damage valves in plumbing fixtures, joints in supply pipes and the water heater itself.

Is a water heater expansion tank necessary?

An expansion tank is always highly recommended if you have a ‘closed-loop system’ caused by any kind of check valve or pressure regulating valve installed on your house’s water supply line. … However, the long-term wear and tear of this excess pressure can reduce the life expectancy of everything in your plumbing system.

Do I need to replace the expansion tank when I replace my water heater?

The pressure should be above 75 psi. If there is no air pressure within the tank, the expansion tank has failed. You will need to replace it with a new one. If there is pressure inside the tank, you’ll need to check the water pressure.

What size expansion tank do I need for a 50-gallon water heater?

For a 50-gallon water heater, you require a 2-gallon expansion tank. Depending on how high your water pressure is, however, you may need to go up a size to a 4.5-gallon expansion tank.

How do I know if my water heater expansion tank is bad?

If it makes a dull thud rather than a hollow sound, your tank is full of water and needs repair or replacement. You can also gauge this by feeling the tank, which will be cool where it’s holding air and warm where it’s holding water. If more than half the tank is warm, you have a problem.

What can I use instead of a expansion tank?

The Thermal Expansion Relief Valve can replace a water heater expansion tank because it functions similarly. Both products absorb the excess pressure in the plumbing system created by thermal expansion.

Can an expansion tank explode?

If your house is heated by warm water and radiators you probably have an expansion tank. … Deal with your expansion tank problems as soon as possible. They can be so serious that your tank could even explode.

What PSI should my expansion tank be?

The recommended water pressure is between 50 and 60 PSI. Thermal Expansion Tanks contain an air bladder which is pressurized with air, and expands and contracts to absorb the expanded water from the water heater. needed. Check the air pressure in the Expansion Tank using a tire gauge.

How often should expansion tank be replaced?

Between five and 10 years is the average lifespan of your tank. If your home’s water pressure matches the air pressure in your expansion tank, you can extend the life of your tank. You’ll need to replace it in some cases.

Where do you put an expansion tank?

An expansion tank is generally installed directly above the water heater by means of a tee-fitting installed in the cold water delivery pipe. The expansion tank is usually installed vertically, though it is acceptable to install it horizontally if it is necessary because of space limitations.

Article first time published on

What happens when expansion tank fails?

Oftenthe diaphragm dividing the two systems will fail, causing the two systems to become one. When this happens, the expansion tank turns into a “dead leg” that will eventually cause damage and premature failure to your water heater.

How much does it cost to install a water heater expansion tank?

The job of the thermal expansion tank is to absorb the extra water volume so that the excess pressure does not cause undue wear and tear on the water heater and other fixtures in the home. The cost to install a new Thermal expansion tank can range from $279 to $443.

How long does an expansion tank last?

The average life of your tank can be anywhere between five and 10 years. You can extend the life of your expansion tank by making sure that your home’s water pressure matches the air pressure in your expansion tank. But in some cases, you’ll need to replace it.

Will a bad expansion tank cause low water pressure?

Before installing an expansion tank, measure the tank’s air pressure charge. When taken from the box, the air pressure in the expansion tanks will likely be lower than your home’s water pressure.

Why is my expansion tank full of water?

Some tanks fail when a leak develops in the diaphragm. This usually causes the tank to fill with fluid and become “water logged.” You can check for this by pressing in the stem of the Schrader valve. If a stream of liquid comes out the tank is toast.

Will a bad expansion tank increase water pressure?

The expansion tank contains air, which is highly compressible. Expanding water from the water heater can flow into the expansion tank, where the air compresses, making room for the increased volume of water. Water pressure in the system doesn’t increase significantly.

Why do expansion tanks crack?

The tank expands and contracts every time the engine is started and warmed up and turned off and cools down. This heat and pressure cycling causes the tank to crack because the design is sub-standard or the wrong material was used. Either way, BMW f’d it up! But there are two sides to the failure issue.

Why are expansion tanks required?

The expansion tank serves as a backup system to prevent overworking your plumbing. The excess water volume, instead of causing too much pressure on the plumbing, rushes into the expansion tank and lowers the pressure in the water heater to safer levels. This ultimately protects it from damage.

Why does water heater expansion tank explode?

Water Expands When It’s Heated in Your Water Heater As water heats up, it can expand dramatically, and if it’s hot enough to turn into steam, this can add even more pressure to the water heater. If the relief valve is malfunctioning, this can lead to an explosion.

Is a expansion tank required by code?

The California Plumbing Code (Section 608.3) and the California Mechanical Code (Section 1005.0) requires a thermal expansion tank, or listed equivalent, to be installed to water heating systems to relieve excessive building pressure during the heating process.

What is the difference between an expansion tank and a pressure tank?

The most significant difference between expansion and pressure tanks is their functionality. An expansion tank handles water expansion and provides protection for water valves and heaters. On the other side, the pressure tank lengthens the lifespan of the pump.

How does an expansion tank work?

Expansion tanks work by equalizing pressure throughout the system. … As hot water enters the heating system, the pressure in the system increases. As pressure increases, the diaphragm in the expansion tank is pushed down. This compresses the air in the tank, creating more space for excess water to enter.

How do I know if I need a new expansion tank?

If your home has a “closed” plumbing system, then yes, you’ll need an expansion tank. You see, homes have either an open or a closed plumbing system. A closed plumbing system prevents water from flowing in the reverse direction (i.e., water won’t flow back into city lines once it enters your home’s pipes).

Can you install expansion tank upside down?

Expansion tanks can be installed in any direction. Whether oriented uprightly, horizontally, or even upside down, the expansion tank will function properly without any adverse effects. When putting an expansion in an abnormal position (specifically sideways or horizontally), make sure to support the tank.

How much does a 2 gallon expansion tank cost?

The cost of an expansion tank ranges from $40 to $200.

Can an expansion tank cause water hammer?

An expansion tank is a small football-shaped tank that is half-full of air. This takes care of absorbing the shock when the fast flowing water is suddenly shut off to stop water hammer. … Without the tank, the water pressure builds up and may cause faucets to drip and other problems.
